Aqualog Smart

AQUALOG Smart is a compact RTU dedicated to the water distribution sector particularly suitable to the government of those stations with a limited number of variables to be monitored.

Equipped of advanced and innovative functionalities, it is the ideal solution to manage data from devices of a different nature.

• Gateway functions
• Real-Time pressure adjustment on the basis of values at critical point (RTCP System)
• Automation of water systems thanks to LADDER LOGIC LANGUAGE installed on board
• Equipped with a powerful WEB Server which makes it accessible from remote
• Real-Time water system monitoring

• Digital inputs: 3 DI 10-30 V DC optoisolated and with protection ESD ± 15 KV
• Digital outputs: 2 DO 10-30 V DC optoisolated and with protection ESD ± 15 KV
• Analogic inputs: 8 AI 12 bit 0-10 V DC (4-20 mA optional)
• Expandibility: up to 160 DI, 64 DO, 32 AI, 16 AO with MODBUS RS232 / RS485 / RS422 / ETHERNET / CANBUS
• Communication ports:
  • 1 RS232
  • 2 RS485 (configurable as 1 RS422 port)
  • 1 Ethernet 10/100 Mb/s
  • 2 CANBUS 2 USB
• Power supply: 10 – 30 V DC
• Consumption: 1,5 Watt (max consumption 8 Watt)
• Environmental conditions: from -20°C to +70°C
• RTC clock: yes
• Memory: 256 MB FLASH / 128 MB RAM
• Memory expansion: Micro SD CARD / USB
• HMI:
  • Local LCD 7″ colour display touch screen: Mod. DE VISU (optional)
  • ALPHANUMERIC 2 x 16 local display with 12 keys (optional)
  • INTERNET MODE: by standard browser
• Case: IP 20
• Size: 125 x 85 x 40 mm DIN rail mount
• Certification: CE
• Data acquisition:
  • Base Time Acquisition: 1″
  • Base Time Storage: 1’ – 1 h
  • Max. Acquisition Variables Num.: 1000
  • Stored Samples Max Num.: 6000000
  • Sample processing: instantaneous, min, max, medium
• Counters: Max Nr. 3 – Range: 32 bit. Conversion into engineering units. Associable to the time derivative for calculation of flow
• Automation: PLC EMBEDDED with LADDER LOGIC STANDARD IEC 61131-3
• Local communication protocols:
  • RS232 / 485 port: MODBUS RTU, DLMS, OMRON FINS, IEC 62056-21, IEC 60870-5-101/104
  • ETHERNET: TCP/IP, MODBUS TCP, SNMP
  • CANBUS: CAN, CAN OPEN
• Remote communication: TRANSMISSION MEAN: GSM / GPRS / SMS / ADSL / PPSTN / UMTS / WI -FI / F.O. for wired networks / VPN / RADIO MODEM
• Protocols and standards for remote communication: MODBUS RTU / SNMP / MODBUS TCP / IP / DLMS / IEC 62056-21 / IEC 60870-5-101/104. Communication mode: REAL-TIME / BATCH / FILE TRANSFER / FTP / OPC (by optional software)
• Messages: SMS, e-mail
• Web facilities: WEB portal with parameter configuration and view of: REAL-TIME, ALARMS, TRENDS
• Alarms: Signalling and managing of alarms and events generated by threshold overcoming / reaching of both physical and logical states. Messages service for the alarms notification.
• OPC: compliant (by OPC server)
• Configuration: from pc using Rainbow configurator
• Integration with Aquaworks, Overland Advanced and Plant View Scada: direct by Wizard
• User application: By LADDER languages / C / C++ in LINUX platform
• Operating system: LINUX EMBEDDED
